Description
Indoor LED Display Module
Geshino High Refresh rate indoor LED Screen Panel, High quality full color SMD indoor LED display module Including the Data Power Cables and 3Years Warranty,
All LED modules With Best Contrast and Color uniformity to ensure the LED display has excellent visual effect.
- High Refresh Rate
- For Indoor Application
- SMD 3 in 1
- 3 Years Warranty
- CE,RoHS,FCC Approved
LED Lamps
For indoor LED display modules, we choose High-Quality Nationstar/Kinglight/Hongsen LEDs from LED Lamps Factory directly which have high color contrast and best color uniformity so as to meet the need for high grayscale and keeping natural color.
IC Driver
To achieve the best visual performance of Geshino indoor LED display panel, we use the best Driving IC, such as MIB5153,MBI5124, ICN2153,ICN2038S with high refresh rate and high grey level with the latest technologies.
72+ Hours Aging Tests
72 Hours aging test (white balance aging (2×24 hours) and video aging (24 hours)) to improve the reliability the indoor LED display modules and ensure the LED modules without broken leds.
Various Pixel Pitch Avaliable
Geshino Indoor LED display Panel has all pixel available from P2mm, P2.5mm, P3mm, P3.91mm, P4mm, P4.81mm, P5mm, P6mm, P7.72mm, P10mm and small pixel series such as 1.25mm,1.53mm,1.86mm, 2mm, 2.5mm, etc.
Product Description
Product Features
- Standardized 640mm*360mm cabinet, standardized 320mm*180mm module, golden 16:9 ratio design.
- Compatible pitch:1.25nmm/1.53mm/1.86mm/2mm/5mm.
- Viewing angle: Horizontal ≥ 140°, Vertical ≥ 120°.
- The cabinet can be seamlessly spliced horizontally and vertically, effectively reducing the visual gap interference, and the overall display of the screen is coherent.
- High brush, low gray, refresh frequency up to 3840Hz, gray level 14Bit (software on 16Bit).
- Dot-to-dot matching of 2K/4K/8K resolutions, fully front-maintained design.
Technical Parameter
320x180mm Series Indoor LED Module
Item | Specification | Module Picture |
Model No. | Indoor Module Series |  |
Material. | Plastic housing | |
Pixel Pitch. | 1.25mm,1.53mm,1.86mm, 2mm, 2.5mm | |
Resolution. | (128*2)*144,208*117,172*97,160*90,128*72(W*H)dot | |
Module Size. | 320*180(W*H)mm |
250*250mm Indoor LED Module Series
Item | Specification | Module Picture |
Model No. | Indoor Module Series | |
Material. | Plastic housing | |
Pixel Pitch. | P2.604mm,P2.976mm,P3.91mm,P4.81mm | |
Resolution. | (128*2)*144,208*117,172*97,160*90,128*72(W*H)dot | |
Module Size. | 320*180(W*H)mm |
Connecting Diagram
Packing and After-sale Service
1 Packing
Plywood case/Honeycomb carton/Flight case option
2 After-sale Service
If need any help during using Geshino display, please for free to contact your salesman.
